Max Spare : S23

Profile : Rod Seals

Details :

S23 is a symmetrical single acting rod seal for standardised grooves. Standard material for S21 is Polyurethane but we can also supply in NBR material (on request). Due to excellent wear resistance properties of polyurethane, the life expected is 3 times that of NBR.

MATERIAL

Polyurethane 92 Shore A

OPERATING CONDITIONS

Temperature Range	:	-30° C to + 100° C
Pressure	:	400 Bar
Speed	:	1.0 m/s

SURFACE ROUGHNESS

Static	:	2.0 µmRa
Dynamic	:	0.3 µmRa

COMPATIBILITY

Mineral oils, bio oils, water soluble & water glycol fluids

APPLICATION

Earth moving equipment, industrial vehicles, agricultural
machinery, cranes, injection moulding machines, telescopic
cylinders, steering cylinders, loading platforms.

FEATURES

Good static and dynamic tightness.
Compact compression, high surface roughness in the groove base is permitted.
Designed for radially restricted housings.

Part No. :

ID : -

OD : -

Thk :

Mould No. :

Stock Items Only

Part No.	ID	OD	THK	Material	Mould No.
S23003CG01	3.17	9.52	3.17	PU	PUA-833
S23003CG02	3.17	9.52	6.35	PU	PUA-832
S230116701	11.09	17.43	3.55	FKM	SUA-2878
S23012Q201	12.00	19.50	5.00	PU	PUA-286
S23015O501	15.87	25.40	4.75	HYT-HYTREL	PUB-125
S230191001	19.00	30.00	8	NBR	SUB-3594
S23020L502	20.00	25.00	3	PU	PUA-665
S23028L503	24.00	30.00	4.50	PU	PUB-135
S230286601	28.00	36.00	5.00	FKM	SUB-4536
S23028L504	28.00	36.00	8.00	PU	PUB-172
S23028L502	28.00	38.00	8	PU	PUB-1706
S23030L503	30.00	43.00	10.00	PU	PUB-292
S23032L501	32.00	40.00	6	PU	PUB-1049
S23035L502	35.00	43.00	5.30	PU	PUB-652
S23035L501	35.00	43.00	6	PU	PUB-1751
S23036L502	36.00	44.00	5.7	PU	PUB-1050
S230368701	36.00	46.00	9.80	PU	PUB-1893
S23038L501	38.00	45.00	6.50	PU	PUB-1657
S23042L501	42.00	50.00	5.90	PU	PUB-1612
S23042L501	42.00	50.00	5.90	PU	PUB-939
S23042L502	42.00	50.00	6.00	PU	PUB-1978
S23045L502	45.00	53.00	7	PU	PUC-871
S230458701	45.00	53.00	8	PU	PUC-606
S230456601	45.00	53.00	8.00	FKM	SUC-1158
S230456701	45.00	55.00	7.30	FKM	SUC-2235
S23050L505	50.00	58.00	8	PU	PUC-1093
S230506701	50.00	60.00	6.00	FKM	SUC-2610
S23055L503	55.00	65.00	10	PU	PUC-1121
S23056L501	56.00	66.00	6.50	PU	PUC-1209
S23059L501	59.50	67.00	8.00	PU	PUC-749
S23060L507	60.00	68.00	8	PU	PUC-1236
S23060L504	60.00	68.00	8	PU	PUC-166
S230606601	60.00	68.00	8.00	FKM	SUC-1159
S23060L506	60.00	70.00	10	PU	PUC-1120
S230636601	63.00	75.00	10	FKM	SUC-2391
S230631101	63.50	82.55	15.49	NBR	SUD-2243
S23065L501	65.00	73.00	8	PU	PUC-879
S23066CF01	66.67	76.20	9.52	PU	PUD-213
S23068L501	68.00	76.00	6	PU	PUD-413
S23075L502	75.00	90.00	10.60	PU	PUD-1037
S230756601	75.00	90.00	10.60	FKM	SUD-2465
S230761101	76.20	95.25	15.49	NBR	SUD-2244
S230800901	80.00	90.00	6.20	NBR	SUD-2052
S23085L503	85.00	97.00	8.50	PU	PUD-892
S23085L501	85.00	97.00	9	PU	PUD-389
S23086L501	86.00	94.00	6.00	PU	PUD-1044
S23088L502	88.00	96.00	5.30	PU	PUD-1087
S23088L501	88.00	96.00	6	PU	PUD-596
S230881101	88.90	107.95	15.49	NBR	SUE-1505
S230906701	90.00	105.00	10	FKM	SUE-1167
S230908701	90.00	105.00	12	PU	PUE-545
S23100L502	100.00	108.00	8	PU	PUE-655
S231011101	101.60	120.65	15.49	NBR	SUE-1504
S23105L501	105.00	113.00	6.30	PU	PUE-255
S23110L503	110.00	118.00	6.30	PU	PUE-850
S23110L502	110.00	125.00	12	PU	PUE-533
S231101101	110.00	130.00	14.60	NBR	SUF-102
S231141101	114.30	133.35	15.49	NBR	SUF-1069
S23120L502	120.00	128.00	6.50	PU	PUF-184
S231271101	127.00	146.05	15.49	NBR	SUF-1068
S231391101	139.70	158.75	15.49	NBR	SUG-930
S23140P201	140.00	150.00	6.00	PU	PUF-336
S23330L501	330.20	355.60	16.58	PU	PUM-117
