The Max Spare style RVB seal is robust seal. RVB (1+5+1) comes with 2 extra Centre Rings to adjust Groove Height. Though it is suitable for split piston, it is extremely suitable for medium duty to heavy duty application. The RVB seal accepts low & high pressure, vigorous conditions & also any misalignment between sealing gaps.
The RVB seal accepts low & high pressure, vigorous conditions & also any misalignment between sealing gaps.
The seal is a combination of a bottom seal, centre ring & pressure ring. The centre ring is the main seal being flexible enough to retain high & low pressures. The bottom seal supports the centre ring from getting extruded against high pressures. The top ring helps in retaining the centre ring profile & distributing pressure equally. In many cases, the RVB seals can also be split to enable ease of fitment.
FEATURES:
- Long life.
- Accepts misalignment & uneven surfaces.
- Any size upto 1500 mm dia. available.
APPLICATION:
- Medium to heavy duty single acting cylinder with split piston.
COMPATIBILITY:
Mineral oils, water soluble & water glycol fluids.
