Profile : Rod Seals


Spareage : S07
S07 Assembly

Details :
S07 is a double acting pneumatic piston seal suitable for small grooves, easy installation due to its special geometry.
MATERIAL
  • Pneumatic Cylinders.
OPERATING CONDITIONS
Temperature Range : -30° C to + 100° C (NBR)
: -40° C to + 220° C (FKM)
Pressure : 16 Bar
Speed : 1.0 m/s
SURFACE ROUGHNESS
Static : 1.6 µmRa
Dynamic : 0.4 µmRa
COMPATIBILITY
Compressed air.
APPLICATION
Nitrile Rubber 80/85 Shore A.FKM Rubber 80/85 Shore A.
FEATURES
  • Low friction.
  • Lubricating film by optimum profile arrangement.
  • Long service lives.
  • Symmetrical profile, easy installation.
  • Pressure admission on one side or on both sides.

Manufactured by: Max Spare Limited
Product ID: 53i


Part No. :
ID : -
OD : -
Thk :
Mould No. :

Part No.IDODTHKMaterialQtyActionsMould No.
S0700608026.0015.502.00/3.00NBR     SPA-146
S0700809038.0016.002.50NBR     SPA-10553
S070809028.3016.302/3NBR     SPA-6509
S0700808018.6017.602/3NBR     SPA-10558
S070809018.8016.002.30NBR     SPA-6499
S0700920019.0015.501.56/2.20NEOPRENE     SPA-738
S0700909029.0016.002.20NBR     SPA-4399
S070909039.0016.002.20NBR     SPA-4464
S07010200110.0016.001.56/2.20NEOPRENE     SPA-736
S07011080111.5017.001.50/2.60NBR     SPA-915
S07012080212.4020.002.00NBR     SPA-5705
S07013100113.0019.002.30NBR     SPA-4454
S07013080213.0025.001.8/2.30NBR     SPA-651
S07013080113.3020.902.00/2.87NBR     SPA-6746
S0714090114.1021.801.9/2.80NBR     SPA-6261
S0714090214.6022.352.30NBR     SPA-6444
S07015080115.0020.001.50/2.30NBR     SPA-551
S07015090715.0022.002.50NBR     SPA-10555
S07015090515.0023.002.20NBR     SPA-4398
S0716080216.0023.602/2.80NBR     SPA-5985
S0716090216.0025.002/2.8NBR     SPA-3184
S0717080117.2023.001.50NBR     SPA-5484
S07020090320.0028.002/3NBR     SPA-10081
S07020080120.0029.002.00/2.80NBR     SPA-461
S07020180120.0029.502.30NBR     SPA-5501
S07020080220.0029.502/2.70NBR     SPA-2337
S07021080121.0031.002.00/2.80NBR     SUB-1388
S0722090122.0031.502.3NBR     SPA-3606
E07025661825.0033.006FKM     SUB-3633
S0730100130.0041.002.30/3NBR     SPA-876
S0732100132.0038.002/3NBR     SPA-8668
S07036090136.0048.002.5/3.50NBR     SPA-12761
S0738090138.0048.002.50/3.50NBR     SPA-6056
S0738090238.0050.003NBR     SPA-9549
S0740100140.0052.002.20/3NBR     SPA-8185
S07040P40140.0055.002.00NBR     SUC-3283
S0742090142.6054.602.50/3.50NBR     SPA-6452
S0745090145.0059.002.50/3.50NBR     SPA-8695
S07050090150.0064.002.5/3.50NBR     SPA-13035
S0750090250.0064.002.50/3.50NBR     SPA-6532
S0750090350.0064.002.50/3.50NBR     SPA-9001
S0751090151.5059.103.70NBR     SPA-6401
S07057080157.2071.203.00/4.00NBR     SPA-283
S0759650159.0073.003/4FKM     SPA-9564
S07060090160.0076.003/4NBR     SPA-13036
S0760090160.0076.003/4NBR     SPA-6453
S0775090375.0087.004.50/5.50NBR     SPA-8198
S0775100175.0089.004.1NBR     SPA-2768
S07077090177.0096.003.70/5NBR     SPA-13095
S07080090380.0090.003.70/4.70NBR     SUD-527
S07080090280.0092.605.40NBR     SPA-530
S0780090180.0094.004.10/5NBR     SPA-7946
S0783100183.8098.855.10NBR     SPA-3686
S0786090286.00100.003.50/5NBR     SPA-6215
S07086080186.00102.503.50/5.10NBR     SPA-5942
S07086070186.00107.009.00NBR     SUE-569
S07089Y50189.00107.403.50/8PU     PPA-206
S0790100190.00105.004.1/5.50NBR     SPA-8304
S071100801110.00129.004/5.60NBR     SPA-12915
S071200901120.00136.004.00/5.00NBR     SUF-1023
S071400802140.00158.006.00NBR     SPA-13088
S071400801140.00168.005.70/8NBR     SPA-10296
S071601004160.00184.505.50NBR     SPA-10166
S07601002160.00188.005.50NBR     SPA-6121
S07601003160.00188.006.20NBR     SPA-6120
S07601001160.00188.006.20NBR     SPA-987
S07631001163.00188.005.50NBR     SPA-9105
S07701001170.00188.005.50NBR     SPA-9207
S07700901170.00198.005.50NBR     SPA-9566
S07770903177.00191.007.50/9.50NBR     SPA-8151
S07771001177.00203.008NBR     SPA-2767
S07801001180.00204.006NBR     SPA-8246
S071930801193.00217.008.00NBR     SPA-321
S071950801195.00221.007.50/10.00NBR     SPA-2694
S07253O401253.00284.008.15FKM     SPA-12849
S07780901278.13305.569.40NBR     SPA-9837




For customised items please Click here
