Max Spare : R27

Profile : Heavy Duty Seals

MATERIALS
NBR / MS
MAX OPERATING CONDITION
Pressure : 0.5 Bar
Temperature : -30° to +100°
Speed :15 m/s

Part No. :

ID : -

OD : -

Thk :

Mould No. :

Stock Items Only

Part No.	ID	OD	THK	Material	Mould No.
R270190801	19.05	38.10	7.95	NBR	SB-8729
R270190802	19.83	47.62	9.52	NBR	SB-9107
R270200801	20.64	47.63	9.52	NBR	SB-8744
R270220801	22.22	50.80	9.52	NBR	SC-7874
R270230803	23.01	38.10	7.92	NBR	SB-8726
R270230801	23.81	47.63	9.52	NBR	SB-8666
R270230802	23.82	38.10	7.95	NBR	SB-8697
R270230804	23.82	52.37	9.52	NBR	SC-7878
R270240802	24.61	40.00	7.95	NBR	SB-9168
R270240801	24.62	47.62	9.52	NBR	SB-8672
R270250801	25.40	41.27	7.92	NBR	SB-2894
R270256401	25.40	41.27	9.52	FKM	SB-9073
R270250802	25.40	44.45	9.52	NBR	SB-5135
R270250803	25.40	44.45	9.52	NBR	SB-8665
R270266401	26.97	44.45	9.52	NBR	SB-2568
R270280801	28.57	44.45	9.52	NBR	SB-9034
R270290801	29.36	53.97	9.52	NBR	SC-7722
R27180310801	31.75	50.80	9.52	NBR	SC-2146
R270310804	31.75	50.80	9.52	NBR	SC-7522
R270340802	34.10	57.20	9.52	NBR	SC-6128
R270340801	34.90	52.40	9.52	NBR	SC-5027
R270340803	34.92	52.37	9.52	NBR	SC-6948
R270340805	34.92	61.89	9.52	NBR	SC-7462
R270350801	35.00	52.00	7.50	NBR	SC-6301
R270370801	37.31	57.15	9.52	NBR	SC-7352
R270380801	38.10	57.15	9.52	NBR	SC-6182
R270386401	38.10	60.32	9.52	FKM	SC-7404
R270380803	38.10	62.00	9.52	NBR	SC-7057
R270390801	39.67	60.32	9.52	NBR	SC-7685
R270410801	41.27	60.32	9.52	NBR	SC-7077
R270410802	41.27	73.02	9.52	NBR	SC-7159
R270420801	42.84	61.89	9.52	NBR	SC-3335
R270426403	42.85	73.02	9.52	FKM	SC-7129
R270426402	42.87	73.02	9.53	FKM	SC-5552
R270430802	43.00	73.00	10.00	NBR	SC-7501
R270430801	43.66	73.02	9.52	NBR	SC-7203
R270440804	44.45	61.89	9.52	NBR	SC-7881
R270440801	44.45	63.50	9.52	NBR	SC-5530
R270440802	44.45	66.67	9.52	NBR	SC-7443
R270446401	44.45	69.85	9.52	FKM	SC-2710
R270450801	45.23	79.37	12.70	NBR	SD-5381
R270460802	46.83	63.50	9.52	NBR	SC-7626
R270470802	47.60	73.02	9.52	NBR	SC-5823
R270470801	47.62	66.67	9.52	NBR	SC-3334
R270470804	47.62	69.85	9.52	NBR	SC-7551
R270470803	47.62	76.20	9.52	NBR	SD-4913
R270486401	48.00	62.00	5	FKM	SC-6685
R270490801	49.20	66.67	9.52	NBR	SC-2457
R270490802	49.22	69.85	12.70	NBR	SC-5755
R270490803	49.22	69.85	9.52	NBR	SC-5803
R270500803	50.00	70.00	9.52	NBR	SC-7562
R270500802	50.01	82.44	9.52	NBR	SD-5205
R270500804	50.74	76.20	9.52	NBR	SD-5334
R270506401	50.80	69.85	9.52	FKM	SC-6957
R270500806	50.80	73.02	9.52	NBR	SC-7896
R270500805	50.80	76.20	9.52	NBR	SD-5392
R270530801	53.97	72.00	9.52	NBR	SC-7205
R270540801	54.76	73.02	9.52	NBR	SC-7723
R270566401	56.36	88.90	9.52	FKM	SD-5006
R270570803	57.15	76.12	9.52	NBR	SD-5288
R270570802	57.15	81.00	9.52	NBR	SD-5245
R270570801	57.15	85.64	9.52	NBR	SD-3986
R270580801	58.75	76.20	9.52	NBR	SD-5209
R270600802	60.30	98.40	9.52	NBR	SD-4984
R270600803	60.32	77.77	9.52	NBR	SD-5359
R270600801	60.33	79.38	9.52	NBR	SD-3570
R270610806	61.11	79.37	9.52	NBR	SD-5389
R270610802	61.11	92.02	9.52	NBR	SD-5020
R270610803	61.89	88.54	9.52	NBR	SD-5180
R270610801	61.90	82.55	9.52	NBR	SD-1937
R270610804	61.92	79.93	9.52	NBR	SD-5187
R270610805	61.92	101.67	9.52	NBR	SE-2936
R270630806	63.44	95.25	9.52	NBR	SD-5333
R270630803	63.50	81.00	9.52	NBR	SD-4095
R270636402	63.50	82.55	9.52	FKM	SD-1867
R270630802	63.50	88.90	12.70	NBR	SD-3817
R270636401	63.50	88.90	9.52	FKM	SD-1783
R270630804	63.50	88.90	9.52	NBR	SD-5314
R270650802	65.10	82.44	9.52	NBR	SD-5265
R270650801	65.10	95.27	9.52	NBR	SD-5064
R270660802	66.67	85.65	9.52	NBR	SD-3031
R270680801	68.26	88.90	9.52	NBR	SD-4183
R270680802	68.27	85.64	9.52	NBR	SD-5408
R270690801	69.85	101.60	9.52	NBR	SE-2715
R270710801	71.42	88.90	9.52	NBR	SD-4793
R270730802	72.23	95.25	12.70	NBR	SD-5206
R270730803	73.02	98.42	9.52	NBR	SD-5259
R270730801	73.03	92.02	9.52	NBR	SD-5111
R270740801	74.62	104.77	10.31	NBR	SE-2817
R270750801	75.41	98.42	9.52	NBR	SD-5197
R270760801	76.20	95.25	9.52	NBR	SD-4482
R270802001	80.00	110.00	10	NEOPRENE	SE-1670
R270900801	90.00	110.00	10	NBR	SE-2507
R271006401	100.00	130.00	12	FKM	SF-1462
R271010801	101.34	127.00	12.70	NBR	SF-2621
R271106401	110.00	130.00	12	FKM	SF-1440
R271260801	126.75	152.40	12.70	NBR	SG-1911
R272070801	207.00	230.00	11.00	NBR	SK-999
R272540801	254.00	279.40	14.30	NBR	SN-623
R272800801	280.00	310.00	16.00	NBR	SR-1460

For customised items please Click here
