ACE -Rotary Standard Seals & , Sealing Solutions Manufacturer, Supplier, Exporter| Spareage Seals Mumbai India

Max Spare : R19

Profile : Standard Rotary Shaft Seals

MATERIALS
NBR / MS
MAX OPERATING CONDITION
Pressure : 0.5 Bar
Temperature : -30° to +100°
Speed : 10 m/s

The ACE is similar to AIC but has a higher retention in the bearing housings due to Metal Cover.

Part No. :

ID : -

OD : -

Thk :

Mould No. :

Stock Items Only

Part No.	ID	OD	THK	Material	Mould No.
R190120801	12.00	20.00	7	NBR	SB-6067
R190136401	13.80	27.00	8.00	FKM	SB-8035
R190150801	15.00	24.00	7	NBR	SB-6071
R190166402	16.66	28.57	8.22	FKM	SB-4799
R190170801	17.00	28.00	6.5	NBR	SB-2110
R190170802	17.00	28.00	8	NBR	SB-4112
R190170803	17.00	40.00	7.00	NBR	SB-7379
R190176603	17.44	30.17	8.00	FKM	SB-8558
R190176602	17.46	28.56	15.00	FKM	SB-8346
R190176601	17.47	28.58	8.00	FKM	SB-7535
R190180801	18.00	34.00	7	NBR	SB-4512
R190180864	18.00	34.00	7	FKM	SB-5986
R190186602	18.98	30.17	8.00	FKM	SB-8559
R190186601	18.99	31.52	8.00	FKM	SB-7058
R190200803	20.00	32.00	7	NBR	SB-2841
R190200804	20.62	34.92	9	NBR	SB-5044
R190230801	23.00	52.00	8	NBR	SC-4306
R190240801	24.00	40.00	7	NBR	SB-6039
R190240802	24.00	66.00	7.00	NBR	SC-6434
R190256401	25.00	35.00	7.00	FKM	SB-7327
R190251101	25.00	47.00	10	NBR	SB-2994
R190250801	25.40	38.07	11.88	NBR	SB-6007
R190286401	28.00	48.00	10.00	FKM	SB-7908
R190280801	28.50	44.00	20.00	NBR	SB-8440
R190326401	32.00	48.00	7.00	FKM	SB-8018
R190320801	32.00	52.00	9	NBR	SC-2730
R190340801	34.00	91.00	7.00	NBR	SD-4403
R190356401	35.00	45.00	10	FKM	SB-4197
R190350801	35.00	52.00	12.00	NBR	SC-5666
R190386401	38.00	52.00	8	FKM	SC-5044
R190460801	46.00	75.00	11	NBR	SC-1453
R190470801	47.62	69.85	12.70	NBR	SC-6605
R190480801	48.00	65.00	12.00	NBR	SC-6110
R190500801	50.00	72.00	8	NBR	SC-2402
R19050T201	50.00	110.00	12.0	SILICON	SE-2542
R190500802	50.80	76.20	23.81	NBR	SD-4771
R190550801	55.00	90.00	10	NBR	SD-2764
R190550802	55.00	90.00	10	NBR	SD-2894
R190570801	57.15	76.20	12.70	NBR	SD-4320
R190580801	58.00	75.00	15	NBR	SC-2925
R190580803	58.00	86.00	23	NBR	SD-2705
R190606403	60.00	75.00	8.00	FKM	SC-5821
R190600803	60.00	80.00	8	NBR	SD-1199
R190600805	60.00	90.00	12	NBR	SD-153
R190606405	60.00	90.00	13.00	FKM	SD-4059
R19065D501	65.00	85.00	17	HNBR	SD-1527
R190650801	65.00	90.00	12	NBR	SD-152
R190700801	70.00	90.00	10	NBR	SD-3736
R190700802	70.00	125.00	20.00	NBR	SE-2377
R190756401	75.00	100.00	13	FKM	SD-2330
R190750801	75.00	100.00	20	NBR	SD-1821
R190750802	75.00	105.00	13	NBR	SE-2111
R190760801	76.20	101.60	17.5	NBR	SE-345
R190800801	80.00	105.00	20	NBR	SE-1979
R190806401	80.00	110.00	12	FKM	SE-1589
R190850802	85.00	105.00	8	NBR	SE-1538
R190856401	85.00	110.00	13	FKM	SE-308
R190860801	86.00	130.00	15.0	NBR	SF-2236
R190880801	88.90	114.30	15.60	NBR	SE-1750
R190906402	90.00	115.00	13	FKM	SE-1275
R190906403	90.00	120.00	17.00	FKM	SE-2246
R190950801	95.00	120.00	12	FKM	SE-299
R190970801	97.00	120.00	16	NBR	SE-819
R191000801	100.00	120.00	13	NBR	SE-497
R191006401	100.00	125.00	12	FKM	SE-321
R191040801	104.00	135.00	15.00	NBR	SF-2358
R191090801	109.00	140.00	22	NBR	SF-839
R191100801	110.00	130.00	12	NBR	SF-1077
R1901106401	110.00	140.00	22.00	FKM	SF-2266
R191206401	120.00	150.00	22.00	FKM	SF-2383
R191250801	125.00	155.00	22	NBR	SG-198
R191250801	125.00	160.00	15	NBR	SG-710
R191300801	130.00	150.00	13	NBR	SF-464
R191406401	140.00	170.00	15	FKM	SG-565
R191450801	145.00	165.00	16	NBR	SG-154
R191520802	152.40	177.80	24.6	NBR	SH-723
R191650801	165.00	195.00	12	NBR	SH-569
R191846401	184.15	222.25	15.87	FKM	SJ-1053
R191856401	185.00	210.00	13	FKM	SJ-716
R192000801	200.00	230.00	15	NBR	SK-512
R192150801	215.00	250.00	15	NBR	SK-173
R192280802	228.00	250.00	35	NBR	SK-268
R192420801	228.00	290.00	23	NBR	SN-122
R192420801	230.00	280.00	15	NBR	SN-131
R192600801	260.00	290.00	15	NBR	SN-414
R192981001	298.45	336.55	22.22	NBR	SR-1129
R193470801	347.26	367.50	19.05	NBR	SR-505
R194046401	404.81	439.73	28.56	FKM	SS-1103
R194200801	420.00	480.00	25.00	NBR	SS-2102

For customised items please Click here
